Purpose
- For floor connections
- For renovations, conversions and new buildings
- For wall connections with drain height > 23cm
- For replacing low-hanging surface-mounted cisterns
- For replacing floor-standing WCs with surface-mounted cisterns
- For connecting Geberit AquaClean Sela, floor-standing WCs
- For mounting on finished floors
- For mounting in front of drywall and solid walls
Features
- 2-quantity flushing
- Compensation of construction tolerances possible
- Front cladding made of glass (ESG)
- Cistern insulated against condensation water
- Side cladding made of brushed aluminum
- Self-supporting
- Flush volume adjustable (large flush volume setting range: 4.5 / 6 L & small flush volume 3 L)
- Soft touch buttons for flush release and odor extraction
- Orientation light and odor extraction activate when approached
- Orientation light adjustable in seven colors
- User detection report adjustable
- Day/night detection for orientation light adjustable
- Odor extraction with ceramic honeycomb filter, can be mounted without tools
- Ceramic honeycomb filter for odor neutralization can be replaced without tools
- Automatic switch-off of odor extraction after predefined running time
- Mains connection with three-core flexible sheathed cable
- Water connection on the side
Scope of delivery
- Water connection set with angle valve R 1/2
- Sink elbow extension 160mm
- Connection piece made of PE-HD, diameter 90mm
- Sleeve made of EPDM, diameter 44 / 55mm
- transition sleeve made of PE-HD, diameter 90 / 110mm
- 2 threaded rods M12
- Culled socket for mains connection
- power supply unit
- fixing material
Colors:
- Front: slate look, concrete look, glass lava, glass white, glass sand-grey, glass black
- Side panel: Aluminum, aluminum black
Manufacturer:
Geberit International AG
Schachebstrasse 77
CH-8645 Jona
Person responsible:
Geberit Vertriebs GmbH
Theuerbachstr. 1
DE-88630 Pfullendorf
E-mail:
sales.de@geberit.com
**Badquadrat Shop Price without additional discount
Artikel zum Warenkorb hinzugefuegt
Geberit Monolith PLUS sanitary module for stand-alone toilet, 101cm, water connection on side, with P-connection pipe
