• hansgrohe Tecturis E
• 1 x single lever bath mixer

Product details:

• wall-mounted, surface-mounted
• for two consumers
• Spray type: WaterfallStream
• Ceramic mixing system
• Adjustable temperature limiter
• Intrinsically safe against backflow (in accordance with DIN EN 1717)
• Equipped with silencer
• Handle: Lever handle, Select pressure diverter
• with automatic reset
• AirPower: water jet enriched with air
• Material: brass
• Suitable for instantaneous water heaters

Technical specifications:

• Pitch: 150 ± 12 mm
• Projection: 213 mm
• Flow rate (bath spout) at 3 bar: 25 l/min.
• Flow rate (hand shower) at 3 bar: 14.5 l/min.
• Connection type: S-connections
• Connection size: DN15
• min. Operating pressure: 1 bar
• max. operating pressure: 10 bar

Scope of delivery:

• Single lever bath mixer, rosettes
• S-connections and installation instructions
