hansgrohe ShowerSelect Comfort Q thermostat, concealed, 2 consumers, Soft Edge rosette

• hansgrohe ShowerSelect Comfort E
• 1 x concealed thermostat

Product details:

• for two consumers
• Simultaneous use of several consumers
• large Select button - convenient on/off switching of a consumer
• Volume control with stop function
• Thermostat cartridge for regulating the temperature
• Start/stop valve for operating the appliances
• Flat rosette - more space in the shower
• Soft Edge rosette - can be subsequently adjusted by +/- 3
• Pre-assembled function block - easy installation
• Handles always at the same height regardless of
• the installation depth of the basic body
• Adjustable temperature limiter
• Safety lock at 40 °C
• Thermostat offers the option of thermal disinfection
• Material (handles/button): Metal
• Thermostat is supplied with Rain small and large buttons,
• as well as with the hand shower, splash and bath buttons

Technical data:

• Connection type: iBox universal 2 base unit (item no.: 01500180)
• Basic body not included, please order separately.
• Max. flow rate at 3 bar: 22.1 l/min.
• flow rate upper outlet: 20 l/min.
• flow rate lower outlet: 20 l/min.
• min. Operating pressure: 1 bar
• Max. operating pressure: 10 bar
• Noise group: I
• flow rate class: B

Scope of delivery:

• Thermostat, function block
• Mounting material and installation instructions
