BWT AQA smart 1-column soft water system, model 2019

• connection nominal diameter 32 (G 1 1/4")
• Nominal flow rate 1.7 m³/h
• Accommodation units can be set on the control 1-2 / 3 / 4
• Dimensions (HxWxD) 630x390x580
• mains connection 230/50
• Rated pressure PN 10
• Operating pressure 2.5-8bar
• Water/ambient temperature max. 30/40C°

• perfect limescale protection in the bath and in the pipe system
• up to 50% less cleaning and detergent
• Lower energy consumption and lower heating costs
• höst efficient technology
• Salt consumption 0.45 - 0.53 kg per m³ at 20° dH to 8° dH
• Water consumption 33.5 - 36.1 l per m³ at 20° dH to 8° dH
• Höhe safety overflow 27.5 cm

Scope of delivery: Microprocessor control, multi-way control valve, precision flow meter for brine, dehydrator with exchange resin, cover, storage room for regenerant, brine room, power supply unit with cable and mains plug, connection module 1"Multiblock module X 1", connection set DN 32/32 DVGW, 2 m flushing water hose, 2 m overflow hose 18 x 24, fixing material, AQUATEST-Hürtepr;t, connection fitting, corrugated pipe hoses, siphon
