HÜPPE Design pure

1x 4-corner pivot door with fixed segments with fitting

Glass profile

• Toughened safety glass (ESG) 6mm
• Profiles made of high-quality anodized aluminium

Product features

• For installation in recess and for combination with side panel or as corner entry
• Partially framed door with one glass panel with fixed segment
• Design handle
• With stabilizer (inside)
• Adjustment option in wall profile 15mm
• Can be installed with threshold protection strip (height 10 mm) or without thresholds
• Continuous magnetic strips and sealing profiles, as well as water-repellent horizontal sealing strip
• Fittings with lift and lower mechanism and flush with the glass surface on the inside
• Installation without visible screws in the area of the wall strip
• Installation status: partially assembled
• Right-hand fixing

Dimensions

• Height 197cm
• Width fixed panel right: 26.5 - 28 cm
• Adjustment range in recess 2.5 cm
• Adjustment range with side panel 1.5 cm
• Bath installation dimensions in alcove: 88.5 - 91 cm
• Bath installation dimension with side panel / as corner entry: 88.5 - 90 cm
• Standard entry width: 81.4 cm
• Entry width as corner entry: 81.4 cm
• Entry width in alcove: 57.2 cm
• Entry width side wall: 57.2 cm
• Floor-level installation possible
• Installation on tiled floor and shower tray possible

Scope of delivery:

• Included in delivery: Fixing materials, installation instructions

This is only half of a combinable shower enclosure. For a complete shower enclosure, please also order another corresponding item from the series!

A niche extension set (item no.: 8P9904 up to 2000mm height or item no.: 8P9980 for made-to-measure) is used to install the swing door in a niche. Please order separately!

The specified dimensions of the shower enclosure only refer to installation on shower trays. For floor-level installation, the dimensions differ, please specify the exact dimensions of the shower area before ordering!
We recommend a measuring and installation service for this item!
