- Hüppe Alpha 2
- 1 x swing door, 4-corner, fully framed
Product features:
- for installation in a recess
- for combination with Alpha 2 side panel
- Framed door with two glass panels
- opens inwards and outwards
- profiles and handle strips made of high-quality anodized aluminium
- Adjustment option in the 23 mm wall profile
- Lift and lower mechanism with 5mm lifting effect
- with floor profile (height 41mm)
- Continuous magnetic strips in the handle strip for optimum door closure
- and water-repellent horizontal sealing strip
- Suitable for installation on shower trays and tiled floors
- Handle: Handle strip
- floor-level installation possible
- Left and right fixing
- Installation status: partially assembled
Glazing options optional:
- Glazing with 2 mm Pacific S art glass or
- 4mm toughened safety glass to DIN EN 12150
- optionally with the easy-care Hüppe Anti-Plaque surface finish (only for toughened safety glass)
Dimensions:
- Height: 2000 mm
- Adjustment range in recess: 46 mm
- Adjustment range with side panel: 45 mm
- Bath installation dimension in recess: 974-1020 mm
- Bath installation dimension with side panel: 985-1030 mm
- Access width: 820 mm
- for installation on tiled floor:
- Installation dimension center glass: 974-1020 mm
- Installation dimension (center of glass) side panel: 965-1010 mm
Scope of delivery:
- Swing door, fixing material and installation instructions
- incl. HÜPPE Keder system - installation without visible screws in the area of the wall strip
Optional installation accessories:
- For a widening by 15mm for a wall rail width of 30.4mm
- the widening profile (item no.: 141001 for 1900mm height and item no.: A21005 for 2000mm height) can be used.
- Please order separately!
- Installation in U-shape possible, U-cabin bracket set required.
- U-cabin bracket set not included, please order separately!
Please note:
- The specified dimensions of the shower enclosure only refer to installation on shower trays.
- For floor-level installation, the dimensions differ, please specify the exact dimensions of the shower area before ordering!
- A measuring and installation service is recommended for this item!
Manufacturer:
HÜPPE GmbH
Industriestraße 3
DE-26160 Bad Zwischenahn
